Omnimount OCSBA - Page 6

PN:888-97-313-W-01 revE
Contents
697-884
Part # Qty Description
P-A 2 1/4-20 x 1/2"
P-B 2 1/4-20 x 3/4"
P-C 2 1/4-20 x 1"
P-D 2 M6 Custom Screw
P-E 2 M5 Washer
P-F 2 M6 Thumb Screw
P-G 2 M6 x 16mm
P-H 2 M6 x 8mm
P-I 2 M4 x 35mm
P-J 2 M4 x 16mm
P-K 2 M6 Nylon Washer
697-964
Part # Description
P-L 4 M5 x 20mm
P-M 4 M5 Washer
P-N 4 M6 x 20mm
P-O 4 M8 x 20mm
697-967
Part # Qty Description
P-P 2 Rectangle Spacers
P-Q 4 Carraige Bolt M6 x 15mm
P-R 4 M6 Washer
P-S 4 M6 Nylock nut
Contents
Part # Qty Descri
ption
1 2
Monitor Plate Attachments
2 2 Soundbar Attachment
P-A P-B P-C P-D P-E P-F P-G P-H
P-S
P-L P-M P-N
P-P P-Q P-R
P-O
P-I P-J
P-Q
P-R
P-S
1
2
CAUTION!
MAXIMUM SCREEN SIZE
CAUTION!
MAXIMUM WEIGHT CAPACITY
30 LBS
13.6 KG
10MM
P-K
