Omnimount OE80F

PN:888-61-057-W-00 RevE
9
Screws / Hardware for Flat Panel
Part # Qty Description
M-A 4 Philips screws M4 x 15mm
M-B 4 Philips screws M4 x 30mm
M-C 4 Philips screws M5 x 15mm
M-D 4 Philips screws M5 x 30mm
M-E 4 Philips screws M6 x 15mm
M-F 4 Philips screws M6 x 30mm
M-G 4 Philips screws M8 x 15mm
M-H 4 Philips screws M8 x 30mm
M-I 4 Round Spacers: M6-M8 x 5mm
M-J 4 Round Spacers: M6-M8 x 10mm
M-K 4 Round Washers: M4-M5
M-L 4 Round Washers: M6-M8
Part # Qty Description
W-A 4 Lag Bolts (8mm x 65mm)
W-B 4 Steel Washer
W-C 4 Wall Anchor (10mm OD x 8mm ID)
Contents
Part # Qty Description
1 1 Wall Plate
2 2 Wall Plate End Cap
3 2 Vertical Rails
4 2 Vertical Rail Bumpers
Wall Kit
CONTENTS
1
2
M-A M-B M-C
W-A W-B
M-D M-E M-F M-G M-H M-I M-J M-K M-L
W-C
2
3
3
4
STEP 7
