Technical Specifications
TRM-422
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 24 W
Gain:
Line: 20 dB
Phono: 60-75 dB
Mic: 44 dB
Max. output level: 18 dBu
Frequency range:
Line: 20-20000 Hz
Phono: 40-18000 Hz
Mic: 20-20000 Hz
S/R ratio:
Line: >97 dB
Mic: >92 dB
THD:
Line: <0.04 % at 1 kHz
Phono: <0.13 % at 1 kHz
Mic: <0.008% at 1 kHz
Frequency isolator: -~ to +9 dB
Low/Mid 300 Hz, 18db/oct , Butterworth
Mid/High 4000 Hz, 18db/oct , Butterworth
Inputs:
LINE: RCA L/R
PHONO: RCA L/R
DJ MIC: XLR
AUX: 3.5 mm jack
MASTER SEND: RCA L/R
FX IN: 6.3 mm jack
Outputs:
MASTER: XLR/RCA L/R
BOOTH: XLR/RCA L/R
REC: RCA L/R
MASTER RETURN: RCA L/R
FX OUT: 6.3 mm jack
Headphones: 3.5 mm jack and 6.3 mm jack (min. 32 Ω)
Dimensions (WxDxH): 410 x 285 x 105 mm
Weight: 5.7 kg
Specifications are subject to change without notice due to product improvements.
