LandinggearAssembly
 LandingGearInstallation
4. Unscrewhexagonscrewsonthelandinggearplate,
applythreadlockertohexagonscrews,useittosecure
thecarbonfiberlandinggeartolandinggearplate.
1. Landinggearparts
2. Installwheels,securewheelswithgasketandscrew.(Apply
threadlockertoscrews)
3. Putthecuffthroughthelandgearbeforeinstallthewheel
5. Putlandinggearcoverplateintoaslotandstickitwith
transparenttape.
