OMPHOBBY EDGE 540 - Tail Wheel Assembly; Tail Wheel Installation Steps

ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
TailwheelAssembly
Installthetailwheelassemblyusingwashersandsockethead
screws.PleaseapplyanaerobicadhesiveandlockthreeM3
fixingscrewsbeforeinstallation.
 TailWheelInstallation
LandinggearAssembly
6. Securethecuffswithscrews.Becarefultonotbreakthe
screws.Ifthescrewseemstobedifficulttoinsertuseadrill
toopenupthehole.(Somepeoplehavefoundtheyprefera
dobofsiliconeinsidethecuffholdthemsecure.)
