OMPHOBBY EDGE 540 - Control Horns Assembly; Control Horn Preparation and Attachment

ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
ControlHornsAssembly
1. Carefullylocatetheslotswhichhavebeenmadeonelevators,
ailerons,rudder,lightlycutthroughthecoveringbutnotinto
thebalsasheeting.
2. Usesandpapertoscufftherootofcontrolhornsforagoodglue
bond.Trytoinsertitintothemountingslotstoadjustthe
positionfirst.
3. Putthecontrolhornsreinforcingpiece,dropthehornsinthe
holes,positionedcorrectlywhenthehornsaredirectlyabove
thehingeline,thenstickmaskingtapearoundthereinforcing
pieceasshowninthepicture,cutabout1mminsidewithaknife
andremovethecovering,belowtoexposethepre‐cutslots.
