ServoAssembly
 ElevatorServoAssembly
Installservosasshownwiththeservolabelfacingtowardtherear
ofthefuselage.
Installtheservoarmintheverticalposition.Adjustthepushrod
lengthsothattheservoandelevatorarebothintheneutral
position.
