7
Step 2 / Krok 2 / Schritt 2
Bearing-MR63ZZ
Kul. ložisko MR63ZZ
Kugellager MR63ZZ
Ø3xØ6x2.5mm
Servo Mount
Lože serva
Servo Befestigung
Bearing-MR63ZZ
Kul. ložisko MR63ZZ
Kugellager MR63ZZ
(Ø3xØ6x2.5mm) 1x
Countersunk Hex Socket Screw
Imbusový šroub zápustný
Senkschraube mit Innensechskant
(M1.6x4mm) 2x
Countersunk Hex Socket Screw
Imbusový šroub zápustný
Senkschraube mit Innensechskant
M1.6x4mm
