22
51 F-TM forced terminal block F-TM Forced terminal block
52 RDY ready function ATR
permission
53 SP-SET special 2nd function KHC Integrated power clear
64 EMR emergency shutoff - -
255
No
function
- no No allocation
The difference of multi-function Output Settings
There are some difference of multi-function Output Settings between 3G3JX and 3G3MX2-V1. Before
setting, to refer the following table. Refer to related product user’s manuals.
Data No. Code Function name Code Function name
0 RUN signal during RUN RUN Signal during RUN
1 FA1 constant speed arrival signal FA1 Constant speed arrival signal
2 FA2 over set frequency arrival signal FA2 Set frequency exceeded signal
3 OL overload warning OL Overload warning
4 OD excessive PID deviation OD Excessive PID deviation
5 AL alarm output AL Alarm signal
6 Dc disconnection detection FA3 Set-frequency only signal
7 FBV PID FB status output OTQ Overtorque/Undertorque signal
8 NDc network error - -
9 LOG logic operation output UV Signal during undervoltage
10 ODc Do not use. TRQ Torque limit
43 LOC light load detection signal LOC Low current signal
