Omron 3G3MX2-A2022-V1 Replacing Guide

31
Communication speed
selection
(Baud rate selection)
1138h C071 144Bh C071
03(2400bps)/ 04(4800bps)/
05(9600bps)/ 06(19.2kbps)/
07(38.4kbps)/ 08(57.6kbps)/
09(76.8kbps)/ 10(115.2kbps)
Communication station No.
1139h C072 144Ch C072 1～247
Communication parity
selection
113Bh C074 144Eh C074 00: No/ 01: Even/ 02: Odd
Communication stop bit
selection
113Ch C075 144Fh C075
1: 1 bit
2: 2 bits
Communication error
selection
113Dh C076 1450h C076
00: Trip
01: Trip after deceleration stop
02: Ignore
03: Free-run stop
04: Deceleration stop
Communication error
timeout
113Eh C077 1451h C077
0: Timeout disabled
1 to 9999
0.01[s]
Communication wait time 113Fh C078 1452h C078 0～1000 1[ms]
FV adjustment 1141h C081 1455h C081
FI adjustment 1142h C082 1456h C082
UP/DWN selection 1149h C101
00︓OFF
01︓ON
- 1469h C101
00: Not store frequency data
01: Store frequency data
-
Reset selection 114Ah C102
00: Trip reset at power-on
01: Trip reset when the power is
OFF
02: Enabled only during trip (Reset
when the power is ON.)
- 146Ah C102
00: Trip reset at power-on
01: Trip reset at power-off
02: Enabled only during trip (Reset
at power-on)
03: Trip reset only
-
Logic operation function A
input
1150h C141 1492h C142
Logic operation function B
input
1151h C142 1493h C143
Logic operator selection 1152h C143 00︓AND/01︓OR/02︓XOR - 1494h C144
00:AND
01:OR
02:XOR
-
Output terminal P1 ON delay 1153h C144 1486h C130
Output terminal P1 OFF 1154h C145 1487h C131
Relay output ON delay 1157h C148 1490h C140
Relay output OFF delay 1158h C149 1491h C141
Motor capacity selection 1165h H003 1503h H003
2nd motor capacity selection 1541h H203 2503h H203
Motor pole number selection 1166h H004 1504h H004
2nd motor pole number
1542h H204 2504h H204
Stabilization parameter 1168h H006 1507h H006
2nd stabilization parameter 1544h H206 2507h H206
Enter command 0900h - Indefinite value - 0900h - 1 -
2/4/6/8
1[ 極 ]
00:2P/ 01:4P/ 02:6P/ 03:8P
04～23:10～48Pは設定しないでください
-
0. ～ 255.
1[%]
0～255
1[%]
0 ～ 1000
0.1[s]
0～1000
0.1[s]
-
00:0.1/ 01:0.2/ 02:0.4/ 03:0.55/
04:0.75/ 05:1.1/ 06:1.5/ 07:2.2/
08:3.0/ 09:3.7/ 10:4.0/ 11:5.5/
12:7.5/ 13:11.0/ 14:15.0/ 15:18.5
-
00︓0.2/ 02︓0.4/ 04︓0.75/ 06︓
1.5/ 07︓2.2/ 09︓3.7/ 11︓5.5/ 12︓
7.5
0 ～ 2000
0.1[%]
0～2000
0.1[%]
00︓RUN/01︓FA1/02︓FA2/03︓
OL/04︓OD/05︓AL/06︓Dc/07︓
FBV/08︓NDc/10︓ODc（使用しない で
ください）/43︓LOC
-
Same as C021 (Except 33 (LOG1) to
35 (LOG3), 63 (OPO), and 255 (no))
-
Do not change through ModBus
communication. For setting, refer to
"ModBus Setting" (4-78).
-
Please note that 3G3MX2-V1 does not provide the following functions:
Register No. Parameter No.
Overload limit source selection 10BBh b028
2nd overload limit source selection 152Ch b228
AM adjustment 10CFh b080
Monitor display selection 10D8h b089
Overvoltage LAD stop function 10F5h b130
Overvoltage LAD stop function level setting 10F6h b131
Ready function selection 10F9h b151
PID FB upper limit 112Eh C052
PID FB lower limit 112Fh C053
Operator/ModBus selection 1137h C070
AM offset adjustment 1145h C086
Function name
3G3JX
