C200H Standard I/O Units
Name Specifications Model number Shape
Input
Ui
DC Input Units 8 pts 12 to 24 VDC C200H-ID211 A
p
Units
16 pts 24 VDC C200H-ID212 B
AC Input Unit 8 pts 100 to 120 VAC C200H-IA121 A
16 pts 100 to 120 VAC C200H-IA122/IA122V B
8 pts 200 to 240 VAC C200H-IA221 A
16 pts 200 to 240 VAC C200H-IA222/IA222V B
AC/DC Input
Ui
8 pts 12 to 24 VAC/DC C200H-IM211 A
p
Unit
16 pts 24 VAC/DC C200H-IM212 B
Output
Ui
Contact Output
Ui
8 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC221 A
p
Units
p
Unit
12 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC222 B
16 pts 2 A, 250 VAC/24 VAC (For resistive loads) C200H-OC225
5 pts 2 A, 250 VAC/24 VDC (For resistive loads)
Independent commons
C200H-OC223 A
8 pts 2 A, 250 VAC/24 VDC (For resistive loads)
Independent commons
C200H-OC224 B
12 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC222V
16 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC226 Extended
B-shape
8 pts 2 A, 250 VAC/24 VDC (For resistive loads)
Independent commons
C200H-OC224V B
Transistor
OUi
8 pts 1 A, 12 to 48 VDC C200H-OD411 A
Output Unit
12 pts 0.3 A, 24 VDC C200H-OD211 B
16 pts 0.3 A, 24 VDC C200H-OD212
2
8 pts 2.1 A, 24 VDC C200H-OD213 A
8 pts 0.8 A, 24 VDC; source type (PNP); with
load short protection
C200H-OD214
8 pts 5 to 24 VDC; source type (PNP) C200H-OD216
12 pts 5 to 24 VDC; source type (PNP) C200H-OD217 B
16 pts 1.0 A, 24 VDC; source type (PNP); with
load short protection
C200H-OD21A
Triac Output
Ui
8 pts 1 A, 250 VAC C200H-OA221 A
p
Unit
8 pts 1.2 A 250 VAC C200H-OA223 E
12 pts 0.3 A, 250 VAC C200H-OA222V B
12 pts 0.5 A, 250 VAC C200H-OA224
Interrupt Input Unit
1
8 pts 12 to 24 VDC C200HS-INT01 ---
Standard B7A Interface
Units
16 input
pts
Connects to B7A Link Terminals.
C200H-B7AI1
Us
16 out-
put pts
C200H-B7AO1
Analog Timer Unit 4 timers 0.1 to 1 s/1 to 10 s/10 to 60 s/1 min to 10
min (switchable)
C200H-TM001
Variable Resis-
tor Connector
Connector w/lead wire (2 m) for 1 external resistor C4K-CN223
Note 1. If the Interrupt Input Unit is mounted on an Expansion I/O Rack, the interrupt function cannot be used
and the Interrupt Input Unit will be treated as an ordinary 8-point Input Unit. Moreover, Interrupt Input
Units cannot be used on Slave Racks. Use a C200HW-BCjj1 Backplane.
2. The Unit can overheat if more than 8 outputs are turned ON simultaneously.
