Appendix CUnit Current and Power Consumption
209
Unit 26-V supply5-V supplyModel number
Fuzzy Logic C200H-FZ001 0.30 A
---
Temperature
C200H-TC001 0.33 A
Control
C200H-TC002
C200H-TC003
C200H-TC101
C200H-TC102
C200H-TC103
Cam Positioner C200H-CP114 0.30 A
Controller Link Unit C200HW-CLK21 0.30 A ---
PC Card Unit C200HW-PCU01
C200HW-PCS01
1.7 A ---
Model number Max. current supplied
Maximum
5 V 26 V 24 V
power
supplied
C200H-RT001-P 2.7 A 0.6 A 0.8 A 28 W
C200H-RT002-P --- 23 W
C200H-RT201 0.8 A 28 W
C200H-RT202 --- 23 W
Note The sum total of the 5-V, 26-V, and 24-V power consumptions must be equal to or less than the value for the
maximum power supplied given in the above table (28 W or 23 W).
Maximum Current and
Power Supplied
