Y92A-
jj
N
Y92A-
jj
N
315
Precautions
It is possible toopenorclosethefront cover by untightening or tight-
ening the knurled screw.
Be sure totake thespace requiredfortheopening and closing of the
front cover into consideration when installing the Watertight Cover.
The front cover is made of polycarbonbate, which can be cleaned
using water, methanol, or ethanol.
Regularly check the packing, the quality of which will deteriorate
over the process of time.
The front cover can be mounted in any direction.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. Q88-E1-1
