H3CR-H
H3CR-H
57
H3CR-H8L
H3CR-H8RL
H3CR-HRL
15
78.0
6
39 dia
63.7 0.7
44.8 x 44.8
15
78.0
6
39 dia
63.7 0.7
44.8 x 44.8
48
48
48
48
Installation
Terminal Arrangement
8-pin Models
Without Reset Input (H3CR-H8L)
With Reset Input (H3CR-H8RL)
11-pin Model
With Reset Input (H3CR-HRL)
Power supply
(+)
(~)
(--)
(~)
Power supply
(--)(~)
(+)(~)
Power supply
(+)
(~)
(--)
(~)
Reset
input
Reset input
Note: Leave terminal 3 open. Do not use
them as relay terminals.
Note: Leave terminal 6 open. Do not use
them as relay terminals.
