7
UNIT DISPLAY
Diastolic Blood Pressure
Systolic Blood Pressure
Memory Symbol
Pulse Display
Date/Time Display
Low Battery Symbol
Irregular Heartbeat Symbol
Average Value Symbol
Heartbeat Symbol
Deflation Symbol
User ID Symbols
(User A / User B)
IRREGULAR HEARTBEAT SYMBOL
When the monitor detects an irregular rhythm two or more times during
the measurement, the Irregular Heartbeat Symbol ( )
will appear on the display with the measurement values.
The irregular heartbeat rhythm is defined
as a rhythm that varies by less than 25%
from the average rhythm or 25% more than
the average rhythm detected while the
monitor is measuring the systolic
and diastolic blood pressure.
If the irregular heartbeat symbol ( )
displays with your measurement results we
recommend you consult your physician.
Follow the directions of your doctor.
Normal Heartbeat
Irregular Heartbeat
Pulse
Blood
pressure
Pulse
Blood
pressure
Short Long
HEM-741REL 8-29 Final Rev 1/23/06 9:27 AM Page 7
