Programming Instructions and Execution Times Appendix B
174
Function
code
ConditionsExecution
time(
µs)
Instruction
33 DIV 572 When dividing a DM word by a DM word
40 STC 16 Always
41 CLC 16 Always
60 RDM 695 At reset
61 HDM 734 Always
62 ENDW 197 With DM word
63 NETW 58 Always
76 MLPX 212.5 Word, 1 digit (constant) —> word
288 Word, 4 digits (constant) —> word
355 TIM/CNT, 1 digit (TIM/CNT) —> word
431 TIM/CNT, 4 digits (TIM/CNT) —> word
77 DMPX 298.5 Word, 1 digit (constant) —> word
658.5 Word, 4 digits (constant) —> word
456 TIM/CNT, 1 digit (TIM/CNT) —> word
1,080 TIM/CNT, 4 digits (TIM/CNT) —> word
145 When shifting one word
743 When shifting 64 DM words
84 SFTR
136 to 668
When resetting 1 to 64 DM words
44 NOP
42 IL
91 SBS 75 Always
92 SBN 26 Always
93 RET 49 Always
97 IORF 108 When refreshing 1 word
