Omron V680S - Page 36

V680S Series
36
Recommended Ethernet Cable for EtherNet/IP and PROFINET
Recommended Power Cable for EtherNet/IP and PROFINET
Related Manuals
Caution for Radio Regulations
As soon as the V680S Series has been certified to comply with Radio Regulations of each country, the product label will be subject to change to
include a certificate number without any advance notice. For update on compliance with Radio Regulations, refer to "Models with Standards
Certification" on the OMRON website (http://www.ia.omron.com/).
English Cat. No. Japanese Cat. No. Model Name
Z339 SDGR-709 V680S-HMD6@-ETN RFID system V680S Series User's Manual (Modbus TCP)
Z353 SDGR-710 V680S-HMD6@-EIP RFID system V680S Series User's Manual (EtherNet/IP)
Z354 SDGR-711 V680S-HMD6@-PNT RFID system V680S Series User's Manual (PROFINET)
RJ45
1
3
2
6
Shield
M12 straight
1
2
3
4
Shield
Wiring
Cable with Plugs on Both Ends (M12 Straight/RJ45)
XS5W-T421-@MC-K
1
43
2
44.7 54.7
L (cable length)
RJ45
M12 × 1
14.9 dia.
(Plug)
2 1
34
Cable with Plugs on Both Ends (M12 Right-angle/RJ45)
XS5W-T422-@MC-K
14.9 dia.
M12 × 1
32.3
22.5
L (cable length)
54.7
RJ45
(Plug)
1
4
3
2
2
1
3
4
RJ45
1
3
2
6
Shield
M12 right angle
1
2
3
4
Shield
Wiring
Note: For details, refer to the Industrial Ethernet Connectors Catalog ( Cat.No.G019).
40.7
L (Cable length)
50
30 5
M12
×
1
14.9 dia.
XS5F-D42@-@80-@
Straight
1
2
3
4
Brown
White
Blue
Black
Pin No.
Cable color of
core sheath
Wiring Diagram for 4 Cores
L (Cable length)
25.3
28.3
50
30 5
M12×1
14.9 dia.
Angled
Note: 1. Fire-retardant,Robot cable (XS5F-D42@-@80-F) have warm gray covers.
2. For details, refer to the Industrial Connectors Catalog (Cat. No. X082).
