How the nebulizer kit works
7KHPHGLFDWLRQWKDWLVSXPSHGXSWKURXJK
the medication channel is mixed with
compressed air which is generated by a
compressor pump.
7KHFRPSUHVVHGDLUPL[HGZLWKPHGLFDWLRQ
is turned into fine particles and sprayed
when in contact with the baffle.
Nasal Shower
Upper part
Button
7DQN
(Max 15 ml)
Nasal adapter
Nozzle
O-ring
Lower part
Baffle
Aerosol
Medication
Aerosol
Nozzle
Medication
Compressed Air
