One Control Minimal Series - Product Components and Specifications; Component Identification

1. 9VDC INPUT:
Typical 9V center negative power supplies can be used.
2. LED:
Red indicates when Channel Red is engaged, Blue LED indicates when Channel Blue is engaged.
3. OUTPUT CHANNEL RED:
Send signal to amp/tuner or loop.
4. INPUT JACK:
Plug in your instrument here.
