One products OTB02 - Power Connection; Remote Control Operation; Product Specifications; LED Strip Details

4. Connect the USB plug to any USB port, such as the one
located on the back of your TV or outlet. If no USB power
port is available, a USB to outlet adapter can be used.
*USB to OUTLET Adapter Not Included
- 4 - - 5 - - 6 - - 7 -
5. Use the included IR Remote Control to choose your
favorite color and settings
6. Enjoy your new LEDs!
LED Strip Specification
- LED Type: SMD 5050
- PCB Color: Black
- LED Color: RGB
- LED Quantity: 30 LEDs per 50cm Strip
- Voltage: DC 5V
- Waterproof Class: IP65 Waterproof
- Self-adhesive Back with Double sided Adhesive Tape
- LED Strip: 2 Piece 50cm Length
Remote Breakdown
Function
Turns the LED Lights On or OFF
Increase or Decrease the Brightness of
the LEDs when on a static color
Increase or Decrease the changing
Speed of the LEDs when in a dynamic
theme mode
16 color keys each corresponding to a
single static color. Select a color by
pressing its colored button.
Dynamic Theme mode that jumps
between three colors: red, green, and
blue.
Dynamic Theme mode that creates a
strobe-light eect
Dynamic Theme mode that fades
between 7 colors
Dynamic Theme mode that ashes
between 7 colors
Key
ON/OFF
Speed/Brightness
Static Color Options
Flash
Strobe
Fade
Smooth
Controller Specifications
- Working Temperature: 10°F - 120°F
- Voltage Supply: DC5V-24V
- Output: 3 Circuits
- Connecting Mode: Common Anode
- External Dimension: L
45 mm x W 15mm x H 2.2mm
- Static Power Consumption: <1 W
- Output Current <2 A
- Output Power: 5 V <30W. 12<72W, 24<144W
- Connecting: 4 pieces 5V 5050 RGB LED Strips
- Cable Length:
- USB Cable Length: 70cm
- 3 pieces 30 cm 4-pin connection cable
