ONE COYOTE T - Stairways

Figure 4
5
3. Function
OWNER’S MANUAL
Tilt Wheelchair
3.1 Arm guard
The arm guard is used to prevent
the users from swaying.
NOTE: For this procedure, refer to
Figure 4.
Removing: Press the pin upwards to
remove the bolt, then pull the arm
guard outward.
Installing: Put the arm guard into
chair frame, then install the bolt to
fix the arm guard.
Figure 3
2.4 Stairways
NOTE: For this procedure, refer to
Figure 3.
1. Remove the anti-tippers from the
wheelchair.
2. Similar steps with tippings above.
3. The wheelchair should not be
lowered until the last stair has
been negotiated and the
wheelchair has been rolled away
from the stairway.
3.2 Side guard
The side guard is used to fix the
sitting position of users.
NOTE: For this procedure, refer to
Figure 5.
Operate the adjustment knob to
install or remove the armrest or
