Onida 20XS - Page 26

R759
10 K
270 K
R760
ECO701
VAL
VAL
Q704
R763
220 OHMS
C739
4.7UF/25 V
+
R764
1K
R761
10 K
R762
12 K
MIRC ELECTRONICS LIMITED
ONIDA HOUSE,MAHAKALI CAVES ROAD,ANDHERI(E),BOMBAY-93
NTS
MIRC
ELECTRONICS
APPROVEDCHECKED
DRG. NUMBER
DRAWN
DESIGNED
DATE
mm
FINISH
MATERIAL
GROUP
NAME
MODEL
SCALE -
SHEET -
F
3 PIN
1 2 3
IC651
TDA 7449 DIP20
1098
20 19 18 17 16 15 14 13 12 11
7652 3 41
10 UF/50V
C657
C659
100UF/16V
+
R655
1.5K
R654
2.2K
R656
1.5K
R653
2.2K
10 UF/50V
C658
C655
150KPF
C652
5.6KPF
C654
150KPF
C656
330KPF
C653
330KPF
C651
5.6KPF
R652
2K
R651
2K
9 PIN
D
54321 6 7 8 9
B
3 PIN
1 2 3
DIGITAL EYE
PIN NO. 29 OF MICON
5 V11.5V
11.5V
+ 5 V
9V
CREF
VCC
R OUT
L OUT
RIN 2
RIN 1
LIN 1
LIN 2
MUXOUT L
MUXOUT R
BIN R
BOUT R
BIN L
TREB L
TREB R
DGND
SCL
SDA
BOUT L
AGND
SCL
SDA
INT AUDIO
AV OUT L
AV IN L
AV IN R
AV OUT R
L OUT
R OUT
AUDIO PROCESSOR MODULE
A B C D
4
3
2
1
DCBA
1
2
3
4
