C-701A
62
63
51
54
61
55
53
56
57
58
64
52
59
60
CD MECHANISM EXPLODED VIEW (2)
Ref. No. Part No. Description
51 X2625-984-1 Motor chassis ass'y
52 X2625-769-1 Motor gear ass'y
53 2656-908-01 Sled shaft
54 2625-188-02 Gear A
55 7621-255-15 P2x3, Screw
56 1572-085-11 Leaf switch
57 1639-678-12 Motor PC board
58 1564-722-11 Socket
59 2627-003-02 Gear B
60 2625-191-01 Coil spring
61 2625-477-01 Center ring
62 2641-386-01 Special screw, 2*5
63 2625-625-01 Reinforcement board
64 8848-483-05 KSS-213C, Pickup
(Pickup drive unit)
