Onkyo C-S5VL Service Manual

C-S5VL
IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION
123
45
Q1103/ Q1709: S-80127CNMC-JKM VOLTAGE DETECTOR
(12.7V N-ch open drain, Active L: out)
PIN CONFIGURATION
Top view
PIN DESCRIPTION
No.
1
2
3
4
5
Symbol
DS
VSS
NC
OUT
VDD
Description
ON/OFF switch for delay time
GND
Non-connection
Voltage detection output pin
Voltage input pin
*1
*1. NC pin is electrically open.
Oscillator
counter
timer
VREF
DELAY CIRCUIT
VDD
VSS
DS
OUT
BLOCK DIAGRAM

Onkyo C-S5VL Specifications

General

Frequency range	4 - 50000 Hz
Audio formats supported	MP3, WMA
Total Harmonic Distortion (THD)	0.0025 %
Built-in speaker(s)	No
CD-RW playback	Yes
Device type	HiFi CD player
Product color	Silver
Disc loading type	Tray
Number of optical discs	1 discs
Volume control	Rotary
Headphone outputs	1
Power consumption (typical)	16 W
Package depth	448 mm
Package width	562 mm
Package height	212 mm
Package weight	7000 g

Weight and Dimensions

Depth	318 mm
Width	435 mm
Height	80 mm
Weight	4500 g
