Q331-Q333/Q431-Q433/Q436: TC7WZU04FU TRIPLE INVERTER
Pin Assignment (top view)
V
CC
3A
2Y
1A
GND
3Y
1
2
3
4
2A
1Y
8
7
6
5
Package
C-S5VL
IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION
A Y
L H
H L
Truth Table
