Getting Started
—Continued
■ Adjusting the iPod Adaptor
The iPod adapter needs to be adjusted to match your partic-
ular iPod. Insert your iPod into the RI Dock. If there’s a gap
between the back of your iPod and the adapter, turn the
adapter counterclockwise to close the gap. Turning the
adapter counterclockwise moves it forward. Turning it clock-
wise moves it backward.
Getting to Know the RI Dock
CD-R
HDD/DOCK
TAPE
TAPE
MD
TAPE
DOCK
MD
CD-R
HDD/DOCK
MD
TAPE
MD
CDR
MD CD-R
TAPE HDD/DOCK
CDR
HDD/DOCK
or
MD CD-R
TAPE HDD/DOCK
HDD
iPod slot
Dock connectorRemote control
sensor
RI MODE switch
jack
VIDEO OUT jack
DC IN 12V 1A jack
AUDIO OUT L/R jacks
Set it to match your amp’s
input display (see below).
Amp input
display
RI MODE switch
See your amp’s instruction manual for details on changing the
input display. On some amps, you press and hold the [TAPE] but-
ton to change the input display from TAPE to MD or CDR.
To control your iPod with your amp’s
remote controller, select the matching
remote control mode.
Amp remote
controller’s mode
iPod adapter
Forward
Backward
