Subwoofer SKW-120
Type Bass-reflex with built-in power amplifier
Use For superbass-range reproduction
Frequency response 30-120 Hz (when used with the DR-S2.2)
Maximum output power 60 W
Dynamic output power 120 W
Input impedance 9.5 k ohm
Sensitivity Line 65 mV
Speaker 20-cm woofer
Power supply AC 120 V, 60 Hz
Power consumption 70 W (AC 120 V, 60 Hz)
Dimensions (W H D)
235 493 488 mm
9-1/4" 19-7/16" 19-3/16"
Weight 14.3 kg 31.5 lbs
Others
Auto standby on/off
Satellite speaker D-120
Type 2 way bass reflex
Frequency response 100 Hz-25 kHz
Maximum input power 40 W
Output sound pressure level 82 dB/W/m
Impedance 6 ohm
Speaker 8-cm woofer
1.5-cm tweeter
Cabinet capacity 0.8 L
Dimensions (W H D) 85 120 112 mm
3-3/8" 4-3/4" 4-7/16"
Weight 0.7 kg 1.5 lbs.
Others
Magnetic shielding
Center speaker D-120C
Type 2 way bass reflex
Frequency response 100 Hz-25 kHz
Maximum input power 50 W
Output sound pressure level 85 dB/W/m
Impedance 6 ohm
Speaker 8-cm woofer 2
1.5-cm tweeter
Cabinet capacity 1.5 L
Dimensions (W H D) 265 130.5 79.5 mm
10-7/16" 5-1/8" 3-1/8"
Weight 1.3 kg 2.9 lbs.
Others Magnetic shielding
Audio connection cable (1 pc.)
3.5 m speaker cables (3 pcs.: white, red, green)
8 m speaker cables (2 pcs.: blue, grey)
Spacers for Subwoofer (4 pcs.)
Spacers for Satellite and Center speakers (black, 20 pcs.)
Horizontal mounting base (1 pc.)
Double-faced adhesive tapes (2 pcs.)
Cushioning pads (2 pcs.)
Instruction manual (this manual)
Specifications and appearance may subject to change for
improvement without prior notice.
Accessories
SKW-120/HTP-120
SPECIFICATIONS
