HTX-22HD
EXPLODED VIEWS-2
SPEAKER SECTION
HTX-22HD
SP12
SP08
SP01
SP05
x 4pcs
SP13
(With SP14)
SP14
(Badge)
SP09 x 2pcs
L=35mm
SP11 x 2pcs
L=85mm
SP10
L=95mm
SP06
x 5pcs
SP15
---Rear---
Refer to "EXPLODED VIEWS-1"
