HTX-22HD
EXPLODED VIEWS-3
FRONT SPEAKER (HTX-22HDST)
HTX-22HD
SP22 (With SP23)
SP23
SP22 (With SP23)
SP23
- - - - - SP21 (L&R Speaker Ass’y) - - - - -
TERMINAL :
White / Black
TERMINAL :
Red / Black
[Left] [Right]
<Note>
Nut : mm nut.
<Note>
Nut : mm nut.
