Onkyo LS3100 User Manual

8
En
■ Using the Remote Controller
Remove the plastic film before using the
remote controller.
To use the remote controller, point it at the
controller’s remote control sensor, as shown
below.
■ Replacing the Battery
Use only a battery of the same type (CR2025).
Note
• If the remote controller doesn’t work reliably, try
replacing the battery.
• If you intend not to use the remote controller for a
long time, remove the battery to prevent damage
from leakage or corrosion.
• Remove expired battery as soon as possible to
prevent damage from leakage or corrosion.
Caution
• Replacing the battery incorrectly may cause an
explosion. Use only a battery of the same type or an
equivalent.
(Placing on the floor, etc.)
LAP-301
Remote control
sensor
Approx.
16ft. (5m)
(Mounting to the wall)
LAP-301
Remote control
sensor
Approx.
16ft. (5m)
LAP-301
Remote control
sensor
Approx.
16ft. (5m)
Positive ⊕ side
Pull out firmly in the direction of the arrow
pressing the tab in the direction of the arrow.
Push
Pull
Back side

Onkyo LS3100 Specifications

General

Product color	Black
RMS rated power	- W
Recommended usage	Home theatre
Remotely operated	Yes
Audio output channels	2.1 channels
Amplifier frequency range	50 - 20000 Hz
Signal-to-Noise Ratio (SNR)	93 dB
Total Harmonic Distortion (THD)	0.8 %
Amplifier dimensions (W x D x H)	187 x 120 x 32 mm
Satellite speaker type	2-way
Satellite speaker weight	700 g
Number of satellite speakers	2
Satellite speakers RMS power	40 W
Satellite speaker frequency range	200 - 20000 Hz
Satellite speaker dimensions (WxDxH)	169 x 108 x 78 mm
Subwoofer type	Active subwoofer
Subwoofer weight	5800 g
Subwoofer frequency range	40 - 200000 Hz
Subwoofer drivers quantity	1
Subwoofer dimensions (WxDxH)	261 x 269 x 337 mm
Subwoofer driver diameter (imperial)	6.3 \
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Bluetooth version	2.1+EDR

Weight and Dimensions

Set weight	10500 g
