SE-U55
PACKING-1
Assembly Method
1 Factory-shipped condition
FUNCTION SELECTOR dial LINE
INPUT LEVEL adjustment dial MIN
PHONES LEVEL adjustment dial MIN
DIGITAL IN COAX/OPT selector OPT (Rear side)
WIN/MAC selector WIN (Bottom side)
2 Serial No. of LABEL(POS) AS is stuck on CASE (R).
3 A set is put into POLY BAG, and a tape is stuck and it fixes.
It is staging the printing side of POLY BAG, putting in a set,
and bending a portion to CASE (R) side not much.
Parts Number Parts Name
29362765 LABEL(POS)AS
29100097-1A POLY BAG(350 X 250)
29110149 TAPE(SEROHAN)
FUNCTION SELECTOR dial LINE
INPUT LEVEL adjustment dial MIN
