Onkyo SKS-HT540B User Manual

6/7 PAGE
PWB
R611 CARBON R R16J-820K 1 417348244T
PWB
R612 CARBON R R16J-39K 1 417343934T
PWB
R613 CARBON R R16J-470K 1 417344744T
PWB
R614 CARBON R R16J-120K 1 417341244T
PWB
R615 CARBON R R16J-22K 1 417342234T
PWB
R616 CARBON R R16J-100K 1 417341044T
PWB
R617 CARBON R R16J-1K 1 417341024T
PWB
R619 CARBON R R16J-22K 1 417342234T
PWB
R620 CARBON R R16J-100K 1 417341044T
PWB
R621 CARBON R R16J-1K 1 417341024T
PWB
R622 CARBON R R16J-10K 1 417341034T
PWB
R623 CARBON R R16J-100K 1 417341044T
PWB
R624 CARBON R R16J-100K 1 417341044T
PWB
R625 CARBON R R16J-180K 1 417341844T
PWB
R626 CARBON R R16J-2.2M 1 417342254T
PWB
R627 CARBON R R16J-680K 1 417346844T
PWB
R628 CARBON R R16J-330K 1 417343344T
PWB
R651 METAL O R RS1/2WBJ-12K 1 443521234T
PWB
R901 METAL O R RS1WBJ-820 1 443628214T
PWB
R902 METAL O R RS1WBJ-820 1 443628214T
PWB
R903 CARBON R R16J-10K 1 417341034T
PWB
R904 METAL O R RS1/2WBJ-1K 1 443521024T
PWB
R951 METAL O R RS2WBJ-3.3K 1 441723324F
PWB
R952 METAL O R RS2WBJ-3.3K 1 441723324F
PWB
F901A FUSE HOL NSCT-1P2506 1 25052609T
!
PWB
F901A or FUSE HOL NSCT-1P2031 (1) 25052133T
!
PWB
F901B FUSE HOL NSCT-1P2506 1 25052609T
!
PWB
F901B or FUSE HOL NSCT-1P2031 (1) 25052133T
!
PWB
JL535A SOCKET AS NSAS-2P1335 1 2009990876UL
PWB
P301 PIN JACK NPJ-1PDB556 1 25045774
PWB
P301 or PIN JACK NPJ-1PDB581 (1) 25045801
PWB
P531 PLUG NPLG-2P29 1 25055038
PWB
P631 PLUG NPLG-2P29 1 25055038
PWB
P632A PLUG NPLG-3P131 1 25055147
PWB
P902A PLUG NPLG-2P632 1 25055676
!
PWB
P903A SOCKET AS NSAS-6P1536 1 2009990969UL
PWB
P903B PLUG NPLG-3P150 1 25055166
PWB
P911 WS CLAMP CB-71683(L=50) 1 260261
PWB
E801 RETAINER KANAGU(EARTH) 1 27141059
SKS-HT540
PACKING PROCEDURE PARTS LIS
T
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PACKING
SP01 MIRAMAT SHEET L550 x W1950 x T0.5 (FOR SKW) 1 715-220011-00
PACKING
SP02 PE BAG L1000 x W720 x T0.025 (FOR SKW) 1 700-820013-11
PACKING
SP03 POLY BAG 300 x 100 (FOR AC CORD) 1 700-210001-11
PACKING
SP04 TAPE (SEROHAN) NITTO NO.29 (Yellow) (1) 29110149
PACKING
SP05 POLYFOAM TOP (TOP) 1 720-TS790T-00
PACKING
SP06 POLYFOAM CENTER (CENTER) 1 720-TS790C-00

Onkyo SKS-HT540B Specifications

General

Brand	Onkyo
Model	SKS-HT540B
Category	Home Cinema speakers
Language	English
