Onkyo TX-NR686 User Manual

107
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
 3. Firmware Update
Change the settings for Firmware Update.
Setting Item Default Value Setting Details
Update Notice Enable Availability of a rmware update is notied via
network.
"Enable": Notify updates
"Disable": Do not notify updates
Version - The current rmware version is displayed.
Update via
NET
- Press ENTER to select when updating the rmware
via network.
• This setting cannot be selected if you do not
have Internet access or there is no updatable
rmware.
Update via
USB
- Press ENTER to select when updating the rmware
via USB.
• This setting cannot be selected if a USB storage
device is not connected or there is no updatable
rmware in the USB storage device.
• Wait for a while if "Firmware Update" cannot be selected. It can be selected when the
network function is activated.
 4. Initial Setup
Make the initial setup from the setup menu.
• Wait for a while if "Initial Setup" cannot be selected. It can be selected when
the network function is activated.
 5. Lock
Lock the Setup menu so that the settings cannot be changed.
Setting Item Default Value Setting Details
Setup Parameter Unlocked Lock the Setup menu so that the settings cannot be
changed.
“Locked”: The menu is locked.
“Unlocked”: The menu is unlocked.

Onkyo TX-NR686 Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	7
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	2
Line-out	Yes
Connectivity technology	Wireless
Speakers connectivity type	-
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	57.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Optical drive included	No
Supported video modes	2160p
Supported graphics resolutions	3840 x 2160
HDCP version	2.2
Product color	Silver
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital 5.1, Dolby TrueHD
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	570 W
Package weight	12500 g
Package depth	450 mm
Package width	539 mm
Package height	260 mm

Weight and Dimensions

Depth	379.5 mm
Width	435 mm
Height	173.5 mm
Weight	10000 g
