• The air exhaust fan may be operated
only in a permanent indoor installation
and with its power supply line
concealed.
• The maximum temperature of the
medium handled by the air exhaust fan
and the maximum ambient temperature
are +40°C.
• The air exhaust fan is an IPX4 and
protection class II device. The fan can be
installed in indoor moisture Zone 2, in
accordance with PN-IEC 60364-7-701,
provided that the following requirements
from the air exhaust fan manufacturer
are complied with:
1 - the correct installation in a ceiling
or wall position is maintained with a
proper seal of the power supply line in
the grommet (see Section “Installation”)
2 - the air exhaust duct is secured by
a cover from direct exposure to water
per IPX4 and direct access to live and/
or rotating parts, including the fan rotor
in motion; or the air exhaust duct is at
least 800 mm long and installed with
special tools which will be required
to access the air exhaust fan for
servicing.
• The air exhaust fan must be operated
according to its intended use and within
the performance limits specified on the
nameplate.
• Connect the air exhaust fan to the
building mains (electrical system) with
the following power cable: NYM-O
2x1.5 mm² (H07V-K 2x1.5 mm²) or
NYM-O 3x1.5 mm² (H07V-K 3x1.5 mm²),
maximum outer diameter 7.5 mm,
depending on the optional accessories
provided.
• Do not use the fan to handle the air
with the following content:
- viscous contaminants prone to
deposition in the air exhaust fan,
- corrosive contaminants which may
degrade the air exhaust fan,
- flammable contaminants, including
gas, vapours, mists or particulates
which may form explosive mixtures
with air.
• The d
evices equipped with ball
bearings are designed for a minimum
operating life of 30,000 hours in S1 duty
cycle at the maximum power output and
the maximum
ambient temperature.
• The control system must prevent
extremely frequent power cycling.
Transport and storage
• Keep the air exhaust fans in their
original packaging in a dry, sheltered
room.
• The transport and storage
ambient temperature limits are -20 °C
to +40 °C.
• Protect against impact and shocks.
Transport the air exhaust fan in its
original packaging.
• If the storage time exceeds 1 year,
the motor bearings of the air
exhaust fan must be tested by
turning the fan rotor by hand before
installation. The fan rotor must run
smoothly.
• Dispose of the air exhaust fan at
the end of its operating life strictly
in accordance with environmental
protection and waste management
laws.
• Should it occur, damage caused by
improper transport, handling, storage
or commissioning will be demonstrated
and is not on warranty.
ACCESSORIES
Available optional accessories:
Terminal block (standard version,
no part index suffix). Connect the air
exhaust fan with the terminal block as
shown in the electrical wiring diagram
shown in
Fig. 3.
The air exhaust fan is started and
stopped by a separate on/off switch
installed in the power supply line (and
