Opel 1900 - Page 5

FRONT SUSPENSION 3A- 5
Figure 3A-6 GT Steering Mast Joint
2. Install Hooks J-23697 before jacking up car to
assure proper loading of suspension bushings and
mounts. See Figure 3A-7.
3. Raise front of vehicle and support with stands.
4. Remove front wheels.
5. Remove guard plate. See Figure 3A-8,
6. Remove brake line retainers on both sides. The
brake system remains closed. Unscrew brake calipers
and suspend them in wheel house.
Figure 3A-9 Removing Guard Plate
7. Suspend engine with a suitable engine lifter, simi-
lar to the one shown in Figure 3A-9.
8. Unscrew lower steering mast clamp bolt out of
pinion flange. See Figure 3A- 10.
9. Unscrew front left and right engine mount from
damper block.
10. On top and in the rear, unscrew front suspension
Figure 3A-7 Installing Hooks J-23697
Figure 3A-9 Suitable Engine Liftel
