EXHAUST SYSTEMS
6D- 43
6D-4
Figure 6D-1 Opel 1900 and Manta Exhaust System
G.T. - EXHAUST SYSTEM
KEJ
1
2
3
4
5
6
7
DESCRIPTION
MUFFLER, FRT. W/CTR. EXHAUST
PIPE, FRT. EXHAUST
MUFFLER, RR. W/TAIL PIPE
BUMPER, MUFFLER SUSPENSION - RR.
BOW. MUFFLER SUSPENSION - RR.
BRACKET, MUFFLER SUSPENSION - RR.
DAMPER RING, MUFFLER SUSPENSION -
FRONT AND REAR.
6D-5
Figure 6D-2 GT Exhaust System
