44 Keys, doors and windows
To install the deflectors, the soft top
should be opened.
Fitting of the small wind deflector
● Fold down left rear backrest
3 74.
● Remove the cover from the
guidance between the rear head
restraints by sliding sideways to
the left vehicle side.
● Insert the adapter of the deflector
with the elevation into the
opposite recess of the guidance.
● Slide deflector in the guidance to
the right vehicle side until it
engages.
● Raise rear backrest.
Remove deflector in reverse order.
Fitting of the big wind deflector
● Take the deflector out of the bag.
● Extract the four locking pins of
the deflector: the upper ones leap
out spring-loaded by turning the
pins out of the brackets on both
sides, the lower ones leap out by
lifting the detents at the sliders on
both sides.
● Expand the wind deflector.
