94 Climate control
Climate control
Picture no: 15922s.tif
Heating and ventilation system,
air conditioning system 3
Ventilation, heating and cooling 3 are
combined into one unit that is designed to
provide comfort regardless of the season,
weather or outside temperature.
When cooling 3 is activated, the air is
cooled and dried.
The heating unit heats the air as required in
all operating modes depending on the
position of the temperature switch. The air
supply can be adjusted to suit requirements
by means of the fan.
The buttons for cooling n and air
recirculation 4 are only found on
versions with optional air conditioning
system 3.
Air conditioning system 3 3 98.
Picture no: 15928s.tif
Air vents
At least one air vent must be open while
cooling 3 (air conditioning compressor) is
on in order to prevent the evaporator from
icing up due to lack of air movement.
The interior ventilation can be adjusted
to a comfortable level by adjusting the
temperature switch.
To increase the air supply, turn the fan all
the way up and set the air distribution
switch to M or L.
Heating and ventilation system,
air conditioning system 3................. 94
Air vents ............................................... 94
Heating and ventilation system ......... 96
Air conditioning system 3................... 98
Air intake .............................................. 101
Pollen filter ........................................... 101
Regular operation ............................... 101
Service .................................................. 101
