4. Parts list :
No. Quantity Description Material Size (in mm)
1 1 Base Acrylic 8 x 70 x 70
2 1 Holder Aluminium strip 2 x 10 x 250
2 Holed strip metal 0,5 or 0,8 x 10 x 150
3 1 Shaft Metal axle Ø 3 x 95
4 1 Iron core Machine screw &nut M6 x 25
5 1 Winding Varnished copper wire Ø 0,6 x 2400
6 2 Commutator Double gears 30/10 Zähne
7 1 Contacts Spring steel Ø 0,5 x 500
8 2 Permanent Magnets Ring Ø 18/5 x 5
9 2 Sundries Machine screws M3 x 16
10 2 Sundries Nuts M3
11 6 Sundries Machine screws M3 x 6
12 2 Sundries Washers M4
13 1 Jig Beech wheel Ø 40 x 10
Also needed :
A few drops of a turbo glue ( not included in the pack )
311.619 4g-tube
311.620 10g bottle
