5.4 Mounting of suction pad

Choose correctly sized suction pad depending on weight of element to be lifted and mount suction pad

with 4 screws.

5.5 Transport position / working position

Remove locking pins on both handles. Adjust handles in wished working position and fix handles with

locking pins.

5.6 Activating of device

Turn „ON / OFF“ switch to „ON“.

5.7 Lifting of loads

Place device on clean and dry element to be lifted. Check if all locking pins are mounted correctly.

Load need to be lifted horizontally and with equal weight distribution.

Turn „ON / OFF“ switch to „ON“. As soon as vacuum level of -0,2 bar is reached, load can

be lifted.

5.8 Releasing of loads

Make sure that load is placed on solid ground.

To release load, open external air valve with lever on handle.
