Assembly and maintenance instruction recirculating ball screw
5. Dezember 2007 Page 23Recirculating ball screw assembly and maintenance instruction ; Version 2.0
© 2007
GB
£ Oil all guideways.
£ Re-assemble cross table.
£ Slide the V-ledge on the cross table.
Clamp or adjust it using the lock
screw.
Fig.1-49: Oil guideways and assemble
cross table
Guideways
Cross table
V-ledge
Lock screw
