9
• Always plug the AC adapter into the CTR-107
before you plug it into the AC outlet, and unplug
the AC adapter from the AC outlet before you
unplug its barrel plug from the CTR-107.
Follow these steps to connect the CTR-107 to AC
power.
1. Set the adapter’s voltage switch to 6V.
2. Insert the adapter’s 5.5 mm outer diameter/2.1
mm inner diameter barrel plug into the adapter’s
cord so it reads –TIP.
3. Insert the AC adapter’s barrel plug into the
DC 6V
jack on the CTR-107.
4. Plug the AC adapter into a standard AC outlet.
