CLEANING THE NOZZLE AND CLEANING NEEDLE
If the stove is not functioning satisfactorily and the routine measures above do not help, the nozzle
and cleaning needle may need to be cleaned. Remove the burner plate, use the tip of the multitool
as a screwdriver and unscrew the nozzle. Remove the cleaning needle from the burner. Wipe clean
the cleaning needle body and the inside of the nozzle. Clean the nozzle hole by carefully pushing the
cleaning needle through the nozzle.
CLEANING THE SPINDLE’S FUEL GROOVES
If the stove is still not getting very hot even though you have cleaned the nozzle and cleaning needle,
the spindle’s fuel grooves may need to be cleaned. Unscrew the nut which connects the fuel hose to
the stove using the multitool. Unscrew the control valve fully and pull it out together with the spindle.
Carefully clean the groove running along the spindle close to the tip, using a fingernail, for example.
Take care not to damage the spindle threads.
REPLACING THE FUEL FILTER
If you are still having problems with the stove, the fuel filter may need to be replaced. The fuel filter is
located at the end of the plastic tube on the fuel pump. Unscrew the patterned part of the filter holder
and push the filter out using a pointed object. Make sure the filter holder is clean before inserting
the new filter. If you have problems with the fuel filter, you can use the stove without one for a brief
period. It will be more sooty than usual. Some fuels also tend to flare more if no filter is fitted. Replace
the filter when you get home.
MORE ADVANCED MAINTENANCE AND SERVICE - EN
Fuel filter
Wick
Bottom nut
Pump
leather
Nozzle
Cleaning
needle
O-rings
Pump rod
Pump valve
Quick
coupling
Burner plate
