Introduction
RJ-45
MOUSE
(SERVICE)
HDMI
VGA-OUT
RS-232C
VGA2-IN/YPbPr
VGA1-IN/YPbPr/
VIDEO
AUDIO1-IN
(VGA1/VGA2)
AUDIO2-IN
(VIDEO)
AUDIO-OUT
MIC
431 2 85 7
11
Monitor loop
through only sup-
ported in VGA1-
IN/YPbPr.
RJ-45 Networking Connector1.
USB Connector / Type-B (Connect to PC for Remote Mouse 2.
function)
HDMI Connector3.
VGA-Out Connector (Monitor Loop-through Output)4.
VGA1-In/YPbPr/5. Connector
(PC Analog Signal/Component Video Input/HDTV/YPbPrr/
Wireless function via VGA Dongle)
Composite Video Input Connector6.
Audio 1 Input connector (3.5mm mini jack) 7.
(for VGA1/VGA2)
Audio 2 Input connector (3.5mm mini jack) 8.
(for Video)
Power Socket9.
RS-232 Connector (9-pin DIN Type)10.
VGA2-In/YPbPr Connector 11.
(PC Analog Signal/Component Video Input/HDTV/YPbPr)
Kensington12.
TM
Lock Port
Microphone Input Connector13.
Audio Output Connector (3.5mm Mini Jack)14.
Type B
9 1312
6
10 14
