optrel e3000X - Page 12

12
Battery
Type: Li-Ion rechargeable
Voltage / capacity: 14�8V / 3�25Ah
Charging cycles: > 500
Operating time level 1* 18 h
Operating time level 2* 16 h
Operating time level 3* 13 h
Charging time: approx� 5h
Weight: 420g / 14�815 oz
Colour: black
*min. operating time with new 󰘰lter at room temperature
Noise level
Max� 70 dB(A)
Warning signals Audible and visual alarm for low battery, clogged or
missing 󰘰lter and low air󰘱ow
Filter 1x type TH3P R SL
for TH3P system (Europe)/TH3P system (Australia)
Air hose Length: 1160 mm (elastic upto 1300mm with
protective sleeve)
Diameter: 31 mm (inside)
Weight: 185g / 6.526 oz (without protective
cover)
Colour: black
Weight
1195g / 42.152 oz (incl. 󰘰lter and belt, without battery)
Dimensions
LxWxH: 222 x 213 x 92.6 mm
Standards EN 12941:1998 /A2:2008, EAC TP TC 019/2011, AS/
NZS 1716
Noti󰘰ed body CE 1024, SAI Global
Scope of delivery/Spare parts (see page I, II, lll)
1 e3000X PAPR
2 Main 󰘰lters TH3P R SL 󰘰lter for TH3P system (Europe)/TH3P system
(Australia)
3 Pre󰘰lter
4 Spark arrester
5 Filter cover
6 Standard battery (Lithium-Ion 48 Wh)
7 PAPR-compatible safety helmet
9 Hose
10 Protective cover for air hose (accessories, not included)
Further accessories can be found in the main catalogue or on our website�
Explanation of symbols (see page VI)
A Read operating instructions before use
B Do not open with sharp objects
C Fragile content
D Store with this side facing up
E Protect from moisture
F Noti󰘰ed body identi󰘰cation mark
G Mark of conformity EAC (Russia)
H Contains lithium ions
I Plastic, recyclable
J Recommended storage temperature: 5 C° to +25 C°
K Do not dispose of as domestic waste� Dispose of as hazardous
waste�
Declaration of Conformity
See the Internet address on the last page�
Legal information
This document complies with the requirements of EU Regulation
2016/425 section 1�4 of Annex II�
Noti󰘰ed body
For detailed information see last page�
min. To change the air 󰘱ow level, press the air 󰘱ow button and scroll through
the di󰘯erent levels until the desired level is reached (Fig. 11).
Replacing the main 󰘰lter and pre󰘰lter: If a 󰘰lter alarm is output, the pre󰘰lter
must be replaced (Fig. 12). Please monitor the time between 󰘰lter alarms.
This becomes shorter each time the pre󰘰lter is replaced. If you have
the impression that the change intervals are too short (this is a personal
impression), it is recommended to replace the main 󰘰lter and the pre󰘰lter
(Fig� 13)�
Alarm function
Filter clogging alarm: When the 󰘰lter clogging alarm is tripped, the LED
shows red. Without action, the 󰘱ow levels III and II change to one lower. To
replace the pre󰘰lter and main 󰘰lter, press and hold the On/O󰘯 button for 2
seconds to turn o󰘯 the e3000X. You can now change the 󰘰lters.
Battery alarm: When the battery alarm is triggered, the LED shows red. A
beep is emitted every second; you can continue using the device for approx�
30 minutes�
Storage
The e3000X system and accessories must be stored in a dry place� Protect
it against sunlight, high temperatures, hydrocarbons and solvent vapours.
Maintenance
Check the helmet regularly according to the operating instructions� Check
the face seal and the air nozzle for holes, cracks or other damage and make
sure that the parts are correctly positioned on the helmet (see instruction
manual)� Do not use the system until all worn or damaged parts have been
replaced�
Maintenance schedule
Activity Frequency
Cleaning, disinfection Always after use
Visual inspection Always before and after use
Charging the battery After each use
Replace seal between main 󰘰lter and
blower unit
Replace if the seal is worn or damaged,
but at least 1x per year
Optrel recommends that the unit be serviced at least once a year by an Optel
quali󰘰ed service company. When the device is in storage, the battery must
be recharged every 4 months�
Cleaning and disinfection
Clean the blower, air hose and helmet using a cloth moistened with soapy
water� Allow the unit to dry at room temperature� Do not use aggressive
cleaning agents or solvents, alcohol or abrasive cleaning agents. The
mechanical seal is washable (hand wash, do not spin).
Troubleshooting
Blower does not switch on
→ Make sure the battery is inserted correctly.
→ Make sure the battery is fully charged.
Filter alarm is activated even though the pre- and main 󰘰lters have been
replaced and are correctly installed
→ Internal e3000X error
→ Return the e3000X system to the nearest dealer.
Battery life is too short
→ Battery defective – Replace battery and dispose of defective battery as
hazardous waste�
→ Charger defective - replace.
Technical data
(We reserve the right to make technical changes.)
Nominal protection factor Europe: TH3P/TH2P classi󰘰cation (see page IV)
Australia: P3 classi󰘰cation
Blower unit
Air 󰘱ow rates: Level 1: min. 170 L/min
Level 2: min. 210 L/min
Level 3: min. 240 L/min
Material
PC + ABS
Blower
High-quality, ball-bearing mounted blower motor
Fuse
Electronic fuse
