7
1. Before mounting, ensure that the four fixing screws are
slackened off so that the red mounting dog-legs can move freely.
2. Move each red dog-leg foot to the LEFT into it’s holding slot, and
then insert the speaker into the mounting hole.
3. Using a cross-head screwdriver, slowly turn each fixing screw
clockwise. This will move the mounting dog-legs out of their
slots.
4. Tighten each fixing screw until the mounting dog-legs grip the
ceiling.
MOUNTING THE OS165CC V2.0
