Channel
Connect a latching footswitch (e.g. FS-1) to remotely switch between Clean and Dirty channels. The front panel channel switch is disengaged when using a footswitch. An
Orange FS-1 LED will illuminate when the Clean channel is selected.
AC Mains Input
Refer to ‘Before Using Your Amplifier‘. Connect the supplied IEC cable to the AC Mains Input. Ensure the Power switch is set to OFF before connecting the IEC cable.
Mains Fuse
The mains fuse is located in the pull-out tray underneath the AC Mains Input. If the mains fuse blows, replace only with the exact rating for your region . If the mains fuse
continues to blow contact yourOrange dealer.
100V/120V: T630mA
230V: T315mA
Voltage Selector Switch
IMPORTANT!
Refer to ‘Before Using Your Amplifier‘.
Power Switch
Ensure the amp’s volume controls are set to zero before switching on power to the amplifier. Switch off when not in use.
