Page #3 background imageLoading...
Page #3 background image
Orange Pi 2 User Manual Shenzhen Xunlong Software CO., Limited
www.orangepi.org www.xunlong.tv
Hardware specification
CPU H3 Quad-core Cortex-A7 H.265/HEVC 4K
GPU Mali400MP2 GPU @600MHz, Supports OpenGL ES 2.0
Memory (SDRAM) 1GB DDR3 (shared with GPU)
Onboard Storage TF card (Max. 64GB) / MMC card slot
Onboard Network 10/100M Ethernet RJ45
Onboard WIFI Realtek RTL8189ETV, IEEE 802.11 b/g/n
Video Input
A CSI input connector Camera
Supports 8-bit YUV422 CMOS sensor interface
Supports CCIR656 protocol for NTSC and PAL
Supports SM pixel camera sensor
Supports video capture solution up to 1080p@30fps
Audio Input MIC
Video Outputs
Supports HDMI output with HDCP
Supports HDMI CEC
Supports HDMI 30 function
Integrated CVBS
Supports simultaneous output of HDMI and CVBS
Audio Output 3.5 mm Jack and HDMI
Power Source DC input can supply power, but USB OTG input don’t supply power
USB 2.0 Ports Four USB 2.0 HOST, one USB 2.0 OTG
Buttons Power Button(SW4), Recovery Button(SW2), Uboot Button(SW3)
