TECHNICAL MANUAL28 | ORBEA ORBEA | 29
EN
BLUE PAPER MX JUNIOR · 2021
MX 16 KICKSTAND
MX20-24 KICKSTAND
KICKSTAND
19 MX16 KICKSTAND
ART Nº: Y033
20 MX2024 KICKSTAND
ART Nº: Y024
19
20
VINYL FORK FLEXIBLE MUDGUARDS
25 M/GUARD VINYL. SUSPENSION FORKS
MX20, MX24
ART Nº: X2630001 BLK-RED 1
ART Nº: X2630002 PURP-MIN 1
ART Nº: X2630003 GRA-MOS 1
Attaches to the fork lowers and bridge with
zipties (not included)
26 M/GUARD VINYL. RIGID FORKS
MX16, MX20, MX24
ART Nº: X2580001 BLK-RED 1
ART Nº: X2580002 PURP-MIN 1
ART Nº: X2580003 GRA-MOS 1
EACH CODE INCLUDES THE SELECTED
COLOUR MUDGUARD AND
2 M5x15 BOLTS TO ATTACH THE MUD-
GUARD TO THE FORKS.
