TECHNICAL MANUAL2 | ORBEA ORBEA | 3
EN
BLUE PAPER MX JUNIOR · 2021
INDEX
01 INTRODUCTION 4
Key to symbols
02 ORBEA WARRANTY 6
03 MAINTENANCE 8
Maintenance schedule of the components
Replacement parts
After a crash or an impact
04 USE WARNING 11
Intended use
05 GEOMETRY AND SIZING 14
06 TECHNICAL SPECIFICATIONS 16
07 ASSEMBLY AND SPARES 18
Headset
Axles and rear derailleur hanger
Frame hardware
Digit seatpost
Handlebar
Chainguide-chain cover
Mx16 stabilisers
Mudguards
Kickstand
Bottle holder
Cabling
08 SUSPENSION 31
09 DECLARATION OF CONFORMITY 32
10 ADDITIONAL INFORMATION 34
EN P.03 | ES P.36
